LIQUID AND GAS PROCESSING PLANTS
AND LOADING AREAS
50 &150 lb. units have D.O.T. approved cylinders
and framing components are made of rugged steel and welded
to meet extreme use conditions.
steel parts and cylinders are powder coated to withstand 240
hour salt spray testing. Environment corrosion resistant
paint also available upon request.
units are designed for one man operation. Easily transported
through all types of terrain, narrow aisles and door ways.
Available in wheel variations as noted on individual
specifications sheets. Tires range form 8" x 2",
12.3" x3.5", and 16" x4" semipneumatic
brass cylinder valve and hose valve assemblies are chrome
to use quick release, no-kinking hoses.
units have two (2) choices of chemical, ABC (multipurpose)
ammonium phosphate based and PK (purple K) potassium
bicarbonate based. (Standard chemical not available in 30,
50, and 150 lb. stored pressure units.)
tow loops available for all models upon request.
to ANSI/UL 299 and ANSI/UL 711 standards.
units also available in all sizes and types of agents.
